Long-life asphalt pavement: Red Bluff lessons

Caltrans Senior Engineer Sean Shepard (I-5 Red Bluff job) and Caltrans Resident Engineer John Bailey (I-5 Weed job) share lessons learned on the Long-Life Asphalt Pavement Projects on Interstate 5.


(Photo: William Hook / Flickr)(Photo: William Hook / Flickr)


Editor’s Note: This is a web-exclusive piece to complement “Long Live Asphalt Pavements,” the National Asphalt Pavement Association (NAPA) Special Section in the Better Roads October 2013 print edition (pp. 18-27).

In gathering research for this article, Bob Humer had the following e-mail exchanges with Caltrans Senior Engineer Sean Shepard (I-5 Red Bluff job) and Caltrans Resident Engineer John Bailey (I-5 Weed job) regarding lessons learned on the Long-life Asphalt Pavement Projects on Interstate 5.

Bob Humer: Please elaborate on mix production, traffic control and other logistical issues:

Sean Shepard: Long-life HMA is produced using the same general process as conventional HMA, in a continuous-flow plant having adequate controls on the materials. There are somewhat tighter tolerances on long-life binder content than with conventional “Type A” HMA and this created some challenges with the QC/QA (Quality Control/Quality Assurance) process.

For the “North Red Bluff Rehab” project, traffic control was one of the biggest construction challenges.  Interstate 5 is a four-lane facility within the “long-life” post-miles, and traffic volumes required us to keep both lanes open in each direction during the daytime.

The staging necessary to accomplish this work used an arrangement not frequently seen on Interstates — the traffic lanes in one direction were split, with one of the lanes crossing the median to run against traffic in the other direction, separated by a temporary concrete wall.

With one lane removed from service in a given direction, we were able to shift the remaining lane on to the shoulder enough to install another temporary concrete wall (Type K barrier rail) to protect traffic and construction crews, then roto-mill the full depth of the old Asphalt Concrete (AC) in the other lane, exposing the cement treated base (CTB) underneath.
