Big Bertha, world’s largest tunnel-boring machine, arrives in Seattle

|  April 04, 2013 |

The nearly-assembled Bertha with cutterhead installed. Credit: WSDOT Flickr

The nearly-assembled Bertha with cutterhead installed. Credit: WSDOT Flickr

The “Big” in Bertha’s name isn’t there for the catchiness.

It’s there because it’s apt. With a 57-foot diameter and a length of a football field, Big Bertha is the world’s largest tunnel-boring machine. She’s quite hefty too. Bertha is assembled from 41 parts, the largest of which weighs in at 900 tons.

Big Bertha aboard ship

Bertha aboard the Jumbo Fairweather. Credit: WSDOT Flickr

And she recently received a celebrity’s welcome in Seattle where Bertha will begin digging the Washington State Route 99 tunnel beneath downtown Seattle this summer.

The new tunnel will replace the SR 99 Alaskan Way Viaduct that was opened 60 years ago this week, according to the Washington State Department of Transportation. Replacing the viaduct will cost a total of $3.1 billion. Digging the tunnel alone will cost $2 billion.

The $80 million Bertha traveled 5,000 miles from Osaka, Japan where she was built by Hitachi Zosen. The owner of the tunnel-boring machine is Seattle Tunnel Partners, the contractor chose by WSDOT for the tunnel project.

Bertha even has her own Twitter account and it’s quite entertaining.

Bertha’s a lumbering giant too. Once she’s started digging, Bertha will tunnel beneath Seattle heading north at a pace of 3 inches per minute. She’ll be digging a 1.7-mile tunnel which WSDOT expects to be completed in 16 months.

The WSDOT says the tunnel is expected to open to traffic in late 2015. The department will also be pointing a webcam at Bertha’s progress pretty soon. Click here to check and see if it’s live yet.

Big Bertha cutterhead closeup

Closeup of Bertha’s teeth. The large yellow teeth are “fixed cutters that score a groove in the soil as the machine moves forward.” Credit: WSDOT Flickr
